#6225595 - 03/16/16 01:38 PM DIY Camera solar panel
mooney_ag Offline
Tracker

Registered: 07/05/05
Posts: 537
Loc: Aledo, Texas
Looking to put a solar panels on the cameras to conserve battery life. Moultrie sells one for roughly 90$ but I could do the same with a $25 wgi solar panel for a feeder. Just need to put the proper connector in line to the camera. Anyone done this or know of the correct size connector? Radio shack has 6 different sizes of the co-axial power plug.

Top
#6226070 - 03/16/16 08:22 PM Re: DIY Camera solar panel [Re: mooney_ag]
dgilbert Online   content
6 pack abs

Registered: 09/04/04
Posts: 18695
The way they are making TC now days a set batteries 6 to 9 months, no need for solar panels anymore.

Top
#6226361 - 03/17/16 06:55 AM Re: DIY Camera solar panel [Re: mooney_ag]
GLC Online   content


Registered: 02/25/09
Posts: 4116
Loc: Burleson Texas
Look around your house and junk drawers. You can probably find a few with the right size connection. The tighter connection the better. That is what I did on all of mine. I also picked up the cheap wildgame solar panels. Main thing is when you wire it make sure you have the correct positive and negative leads connected to the right place or the the camera goes "poof".
_________________________


Top
#6226374 - 03/17/16 07:08 AM Re: DIY Camera solar panel [Re: mooney_ag]
billybob Online   content
Extreme Tracker

Registered: 02/28/10
Posts: 3502
Loc: Southlake, TX, Billy Bob Ranch...
This is the one I use on Covert cameras RadioShack 4.0x1.7mm Coaxial DC Power Plug (2-Pack) Catalog #: 2741532 $3.49.
Or buy this one premade http://www.cabelas.com/product/stealth-cam-10-ft-battery-cable/745942.uts#BVQAWidgetID


Edited by billybob (03/17/16 07:59 AM)
_________________________
http://billybobknives.shutterfly.com

Top
#6226602 - 03/17/16 10:05 AM Re: DIY Camera solar panel [Re: mooney_ag]
oldoak2000 Online   content
Veteran Tracker

Registered: 09/16/07
Posts: 2042
Loc: Denton, TX
Originally Posted By: mooney_ag
Looking to put a solar panels on the cameras to conserve battery life. Moultrie sells one for roughly 90$ but I could do the same with a $25 wgi solar panel for a feeder. Just need to put the proper connector in line to the camera. Anyone done this or know of the correct size connector? Radio shack has 6 different sizes of the co-axial power plug.


It's not just a solar panel - it has a re-chargable 12v battery & a charge controller in there as well. gonna be a bit over $25.

Top
#6227141 - 03/17/16 05:33 PM Re: DIY Camera solar panel [Re: mooney_ag]
BuckRage Online   happy
THF Celebrity

Registered: 10/25/10
Posts: 20512
I put solar panels on mine and a feeder battery. Been going on 3 years never had to replace or recharge a battery.
_________________________
You gotta pay to play
-Chip


Top
#6227144 - 03/17/16 05:35 PM Re: DIY Camera solar panel [Re: oldoak2000]
BuckRage Online   happy
THF Celebrity

Registered: 10/25/10
Posts: 20512
Originally Posted By: oldoak2000
Originally Posted By: mooney_ag
Looking to put a solar panels on the cameras to conserve battery life. Moultrie sells one for roughly 90$ but I could do the same with a $25 wgi solar panel for a feeder. Just need to put the proper connector in line to the camera. Anyone done this or know of the correct size connector? Radio shack has 6 different sizes of the co-axial power plug.


It's not just a solar panel - it has a re-chargable 12v battery & a charge controller in there as well. gonna be a bit over $25.



no charge controller. $25 panel straight to the battery then battery to the camera. I sell the batteries so I only had to pay the solar panel but even at $15 for a battery its light years ahead of having to change batteries or worry if they're still good. I hate when when they decide to pop and get acid all over your tc.
_________________________
You gotta pay to play
-Chip


Top
#6244359 - 04/01/16 12:26 PM Re: DIY Camera solar panel [Re: mooney_ag]
Steve Sylvester Offline
Green Horn

Registered: 03/31/16
Posts: 7
Lithium batteries are the way to go with any cam. On average you'll get a season out of them (unless your setup over a feeder) and you don't have to worry about theft or damage.
_________________________
Not all those who wander are lost

Top
#6246801 - 04/03/16 08:56 PM Re: DIY Camera solar panel [Re: mooney_ag]
Jungleexplorer Offline
Light Foot

Registered: 09/11/15
Posts: 45
Loc: Abilene, Texas
I built my own external battery solar packs. The batteries run around $5, the panels $6, the box $4. They have last about 2 and a half years now.









Edited by Jungleexplorer (04/03/16 09:00 PM)
_________________________


I am a proud citizen of the Nation State of Texas, which is part of the union of the United States of America, but shouldn't be!

Top
#6247142 - 04/04/16 09:05 AM Re: DIY Camera solar panel [Re: mooney_ag]
GLC Online   content


Registered: 02/25/09
Posts: 4116
Loc: Burleson Texas
I made mine out of ammo boxes.
_________________________


Top
#6247272 - 04/04/16 10:36 AM Re: DIY Camera solar panel [Re: GLC]
Jungleexplorer Offline
Light Foot

Registered: 09/11/15
Posts: 45
Loc: Abilene, Texas
Originally Posted By: GLC
I made mine out of ammo boxes.


That is like the first one I built back in 2013, only used a waterproof boating box. Still working today. My later design was a result of me wanting to find a way to build one under $20.
_________________________


I am a proud citizen of the Nation State of Texas, which is part of the union of the United States of America, but shouldn't be!

Top
#6247416 - 04/04/16 12:15 PM Re: DIY Camera solar panel [Re: mooney_ag]
BuckRage Online   happy
THF Celebrity

Registered: 10/25/10
Posts: 20512
$6 panel and $5 battery?
_________________________
You gotta pay to play
-Chip


Top
#6247732 - 04/04/16 04:21 PM Re: DIY Camera solar panel [Re: BuckRage]
Jungleexplorer Offline
Light Foot

Registered: 09/11/15
Posts: 45
Loc: Abilene, Texas
Originally Posted By: BuckRage
$6 panel and $5 battery?


Actually the panels I used have dropped in price and are now $4.95 on ebay. Solar Panel on eBay

I use the 9V 2watt 115mm x 115mm x 2mm panels, these panels are actually much stronger then the deer feeder panels which are either 500mA or 1 Watt.

The batteries I use a 6V 4.5mAh (the same as the deer feeder batteries). I get them off of amazon.com in bulk. Right now you can get six for $37.95 ($6.32ea) or 18 for $43.95 ($2.44ea) Here are the links.

http://www.amazon.com/Exit-Sign-Battery-...ref_=pd_ybh_a_2
http://www.amazon.com/dp/B01DI3XACU?psc=1



Edited by Jungleexplorer (04/04/16 04:30 PM)
_________________________


I am a proud citizen of the Nation State of Texas, which is part of the union of the United States of America, but shouldn't be!

Top
#6247799 - 04/04/16 05:05 PM Re: DIY Camera solar panel [Re: mooney_ag]
GLC Online   content


Registered: 02/25/09
Posts: 4116
Loc: Burleson Texas
Good prices tag for later.
_________________________


Top
#6283640 - 05/02/16 12:39 PM Re: DIY Camera solar panel [Re: mooney_ag]
Wilhunt Online   content
Veteran Tracker

Registered: 07/26/13
Posts: 2333
Loc: New Braunfels, San Saba county
Are the wires easy to access on these $4.99 panels?
